AWG Long Barrel Copper One Hole Compression Lugs

AWG Long Barrel Copper One Hole Compression Lugs

Designed for reliable power transmission, our Long Barrel Copper One Hole Compression Lugs combine high conductivity with excellent mechanical strength.

Made from premium copper tubing and protected by electro-tin plating, they resist corrosion and minimize contact resistance. Clear die indexing and color coding simplify installation, while optional peep hole and belled end variants provide greater application flexibility.

Product Application & Trust

Power Utilities

Panel Board

Data Centers

Telecommunication

Power Utilities Data Centers
Panel Board Telecommunication
Request A Quote
Our Product Highlights

Long barrel design ensures superior conductivity and secure crimping performance, while electro-tin plating provides corrosion resistance and extended service life. Color-coded markings enable quick identification for faster and more accurate installations.

Manufactured from high-conductivity copper tubing.
Long barrel design provides enhanced mechanical strength and electrical performance.
Low contact resistance ensures efficient current flow and reduced power loss.
Bright electro-tin plating resists corrosion and oxidation.
Available with peep hole and belled-end options for greater installation flexibility.
Technical Specifications Table

Technical Specifications

CATALOG NO. RANGE WIRE RANGE COLOR CODE
TI 2018 STRRED
TI 2026 STRBLUE
TI 2034 STRGRAY
TI 2042 STRBROWN
TI 2051 STRGREEN
TI 2061/0 STRPINK
TI 2072/0 STRBLACK
TI 2083/0 STRORANGE
TI 2094/0 STRPURPLE
TI 210250 MCMYELLOW
TI 211300 MCMWHITE
